Mainly used for copper stranded wires, aluminum stranded wire, ACSR, insluated cables, and it is also used for copper wire shielded or steel armoring, ect.
JL-400-500-630-800 Planetary Stranding Machine
-
Introduction
-
Features
1. Each cage linked through the ground shaft, and twisting pitch is stable and extensive use.
2. It is available for non-metal taping and metal taping device according to customers?? requirement.
3. Back-twist function by planetary gear train to achieve 100% mechnical back-twist stranding, it is also possible to use a back-twist ring or twist-free. -
Main technical variables
Item Single Wire Diameter（mm) Max Rotation Speed（rpm) Copper Aluminum Al-Clad Steel 6B 12B 18B 24B 36B 48B JC-400 Φ1.5-3.0 Φ1.8-3.5 Φ1.5-3.0 110 97 85 70 62 61 JC-500 Φ1.5-3.5 Φ1.8-4.0 Φ1.5-4.0 110 97 70 70 51 36 JC-630 Φ1.5-4.5 Φ2.0-4.5 Φ1.8-4.5 95 78 68 56 ~ ~ JC-800 Φ1.5-4.5 Φ1.8-5.0 Φ1.8-4.5 ~ 51 45 40 ~ ~
